Hammer union pressure transmitter Model PTEX1-HU
Excavations and pumps Oil and gas
Specifications
Measuring ranges 5000PSI, 10000PSI, 15000PSI and 20000PSI
Accuracy (non-linearity, hysteresis and repeatability) ≤ 0.25 % of span
Working temperature -40 to 80C
Supply voltage 11 to 28VDC
Output 4 to 20mA
Process Connection Hammer Union 1502
Wetted parts Inconel 718 and AIS316
Designed for harsh environments
Applications
Excavations and pumps
Oil and gas
Certificates
ATEX and IECEx certified Zone 0 and Zone 20 Category 1
